SWITCH 4WD 3 POSITION NO CABLE | JCB | 3CX TIER 3 | 701/42700OEM

5.0 on 5 reviews
Part Fit for 2 models
SWITCH 4WD 3 POSITION NO CABLE | JCB | 3CX TIER 3 | 701/42700OEM
12 months warranty on All spare parts offered by MAQ PARTS
Features:
  • Weight: 0.22
  • Can return: Yes
  • Stocks: SF: 1 | VN: 1 | PL: 0 | : 0 |
Sale
ID 011856
Part number 701/42700OEM
Brand JCB
Models 3CX TIER 3 | 4CX TIER 3 |
Stocks SF: 1 | VN: 1 | PL: 0 |
Replace numbers
Manufacturer/Brand OEM PARTS
Delivery days 7 DAYS
The price
After loggin in
Available
Login
Registration
Categories
ELECTRICAL SYSTEM REVERSE SWITCH

Do you need some help?

Your personal MAQ Parts advisor is ready to answer your questions in your own language.

Martin Giurov
E-mail WhatsApp
  • Deliveries worldwide
    We ship parts worldwide
  • 12 months warranty
    for every product
  • 100% Safety
    Only secure payments
  • Hot Offers
    Discounts up to 50%
Number of connections - 1
Type of connection - wire with connector
Number of wires - 6
Number of pins - 6
Current (A) - 12
Voltage (V) - 690
Total length L1 (mm) - 112
Diameter panel mounting D1 (mm) - 22
Build-in length L2 (mm) - 80
Build-in width W1 (mm) - 44
Build-in height H1 (mm) - 50
Length of the cable L3 (mm) - 160
Number of mounting holes - 4
Diameter of the mounting holes D2 (mm) - 3.2
Shortest center distance between mounting holes C1 (mm) - 36
Longest center distance between mounting holes C2 (mm) - 36
Actuators present - YES
Number of positions actuator - 3
Momentary positions present - NO
Cover plate present - NO
Rail mounting - NO

SWITCH 4WD 3 POSITION NO CABLE | JCB | 3CX TIER 3 | 701/42700OEM models

JCB
3CX TIER 3
JCB
4CX TIER 3
Information on technical characteristics, the delivery set, the country of manufacture and the appearance of the goods is for reference only and is based on the latest information available at the time of publication.
Product Part number Price
POSITION SWITCH 4WD WITH CABLE | JCB | 3CX TIER 3 | 701/42700
 701/42700
Get price - Sign in
There are not replace numbers.
